Video Compression

H.264

Preview Resolution

PAL: 704*576 NTSC: 704*480

Compress Resolution

4CIF, DCIF, 2CIF, CIF, QCIF

Video Input

8/12/16 Channels BNC (1.0Vp-p, 75Ω)

Video Output

1 Channel BNC (1.0Vp-p, 75Ω))

Frame rate

PAL: 1/16—25 F/S;  NTSC: 1/16—30 F/S

Stream Type

Mixed stream or Video Stream

Bit rate

16Kbps～2Mbps (Self definition)

Audio Input

8/12/16 Channels, BNC (Linear Electrical Level，Resistance:1000Ω), SNR > 83DB

Audio Output

1 Channel, BNC (Linear Electrical Level)

Audio Compression

OggVorbis

Audio bitrate

16Kbps

Voice Audio input

1 Channel, BNC (Linear Electrical Level, Resistance:1000Ω)

Communication Interface

1 RJ45 10M/100M UTP Network，1 RJ45 for RS232, 1 RJ45 for RS485

Keyboard Interface

1 RJ45

Serial Link Interface

1 RJ45

HDD IDE Interface

4 IDE, support 8 HDD

USB Interface

1, support USB1.1; Support USB flash disk, USB HDD, USB CDR/W

VGA Interface

1, Support 800×600/60Hz，800×600/75Hz，1024×768/60Hz

Switch Alarm Input

8/16 Ports

Switch Alarm Output

4 Ports

Power Supply

90--135VAC or 180--265VAC, 47--63 Hz

Power Consumption

DS-8016HCI 44W(Without HDD)

Working Temperature

-10℃--＋50℃

Working Humidity

10%--90%

Size

19inch (450mm*450mm*95mm)

Weight

7.6Kg (DS-8008HCI without HDD)
